Description
The Xantrex 3000W Inverter Charger delivers a rated power of 3000VA/3000W, designed for reliability and high performance in energy conversion. While it does not operate without a battery or support lithium batteries, it offers efficient power delivery with dual output. The unit operates on 220/230/240VAC with a selectable voltage range of 170–280VAC for personal computers and 90–280VAC for home appliances, and supports a 50Hz/60Hz auto-sensing frequency range. Output regulation ensures a stable 230VAC ±5%, delivering a pure sine wave form with an impressive inverter efficiency of 93.5% and a swift 10ms transfer time.
This inverter charger supports a 24VDC battery system, with a floating charge voltage of 27.6VDC and overcharge protection at 30VDC. Integrated with a solar charger and AC charger, it allows a maximum PV open-circuit voltage of 145VDC and supports an MPPT PV voltage input range of 30V–115VDC. It includes one MPPT tracker and supports up to 1500W PV input power, handling up to 14A PV input current and 60A charge/discharge current.
Communication is facilitated via USB/RS232, and Wi-Fi monitoring is optional. Mechanically, the device measures 310×486×118mm and weighs 7.4kg net, with a gross weight of 9kg. The unit is certified with CE, EMC, and VDE standards, suitable for a wide range of environments with 5%–95% relative humidity tolerance, and operates in temperatures from 0°C to 55°C (storage: -15°C to 60°C).
